€196.80 + VAT
Out of stock
Out of stock
Single phase power supply IN: 120–230 Vac / OUT: 24 Vdc 10 A
| Series | Easy Power |
|---|---|
| Code | XCSL240C |
| Type | CSL240C |
| HS code | 8504403000 |
| INPUT TECHNICAL DATA | |
| Input rated voltage | 120–230 Vac |
| Input voltage AC | 90…132 Vac / 185…264 Vac (1) |
| Frequency | 47…63 Hz |
| Current consumption | 3.5A (120 Vac) / 1.8 A (230 Vac) |
| Inrush peak current | 35 A |
| Power factor | > 0.6 / >0.85 |
| Internal protection fuse | T 6.3 A |
| External protection on AC line | MT: C-10 A / Fuse: T 10 A |
| OUTPUT TECHNICAL DATA | |
| Output voltage range | 24 Vdc ±1% |
| Output adjustable range | 23…27.5 Vdc |
| Continuous current | 10 A at 45°C |
| Overload limiting | 15 A for >30 s |
| Short circuit peak current | 25 A for 400 ms |
| Ripple @ nominal ratings | 50 mVpp |
| Hold up time | 30 ms (120 Vac) / 60 ms (230 Vac) |
| Status indication | LED "DC OK" |
| Parallel connection | possible |
| Redundant parallel connection | possible with external ORing diode |
| GENERAL TECHNICAL DATA | |
| Efficiency | 88% (120 Vac) / 90% (230 Vac) |
| Dissipated power | 32 W (120 Vac) / 27 W (230 Vac) |
| Operating temperature range | –20…+60°C (derating -4 W >45°C) |
| Input / output isolation | 3 KVac / 60 s (SELV output) |
| Input / ground isolation | 1.5 kVac / 60 s |
| Output / ground isolation | 0.5 kVac / 60 s |
| Standard / approvals | EN 60950-1 |
| EMC Standard | EN 61000-6-1, EN 61000-6-2, EN 61000-6-3, EN 61000-6-4 |
| Overvoltage category / pollution degree | II / 2 |
| Protection degree | IP 20 |
| Connection terminal | 2.5 mm² / 2.5 mm² |
| Housing material | aluminium |
| Dimensions (LxHxD) | 63.5x135x140 mm |
| Approximate weight | 920 g |
| Mounting information | vertical on a rail, 10 mm from adjacent components |
| ACCESSORIES | |
| Mounting rail (IEC60715/TH35-7.5) | PR/3/AC, PR/3/AC/ZB, PR/3/AS, PR/3/AS/ZB |
| Alarm contact | no |
| Mounting rail (IEC60715/TH35-15) | PR/3/PP, PR/3/PP/ZB, PR/3/PA, PR/3/PA/ZB |
| APPROVALS AND MARKINGS |    |
For further information see PDF catalog
VPC.2/S Terminal block for female connectors pitch 5.08 mm
with aligned outputs.
The new CSE3 range is part of the Easy Power series, which includes industrial power supplies designed for standard applications with an excellent price/performance ratio.
